Generator Set by Yuchai Engine Power Range：16kw-2400kw
Generator Set by Yuchai Engine Power Range：16kw-2400kw Generator Set by Yuchai Engine Power Range：16kw-2400kw

loading

Generator Set by Yuchai Engine Power Range：16kw-2400kw

Share to:
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button
  • Adopting Yuchai engines, featuring prompt and reliable cold starting performance;
  • Designed with advanced technology, resulting in optimal combustion, low fuel consumption, less noise, as well as compliance with German TALuft emission standard;
  • Rational performance matching design leads to high stability and reliability of the power generation system;
Availability:
Quantity:
Inquire Add to Basket
Product Description


微信图片_20240115191342

50HZ

Model Power(kw) Power(kva) Engine Model Engine Power(kw) Size(mm)
Main Reserve Main Reserve Main Reserve
WD-16GF 16 17.6 20 22 YC4V35-D20 23 25 1700*700*1050
WD-16GF 16 17.6 20 22 4D24G4/A 18.5 20.4 1400*500*950
WD-16GF 16 17.6 20 22 4D24G6 18.5 20.4 1400*500*950
WD-18GF 18 20 22.5 25 YCDV254FHZ-25 20 22 1600*650*1140
WD-20GF 20 22 25 27.5 4D24G2/A 21.5 23.6 1450*500*1000
WD-20GF 20 22 25 27.5 4D24G7 21.5 25.4 1450*500*1000
WD-22GF 22 24.2 27.5 30.25 YCDV254FHZ-35 25 27.5 1600*650*1140
WD-24GF 24 26 30 32.5 YC4V45Z-D20 30 33 1800*600*1150
WD-24GF 24 26 30 32.5 4D24TG2/A 28 30.8 1500*550*1000
WD-24GF 24 26 30 32.5 4D24TG2 28 30.8 1500*550*1000
WD-25GF 25 27.5 31.25 34.375 YCDV254FHZ-40 30 33 1650*700*1200
WD-30GF 30 33 37.5 41.25 YC4V55Z-D20 38 42 1700*700*1050
WD-34GF 32 37.4 40 46.75 YCDV254FHZ-50 36.8 40.5 1850*760*1200
WD-32GF 32 35.2 40 44 4D24TG0/A 36 39.6 1600*550*1050
WD-32GF 32 35.2 40 44 4D24TG0 36 39.6 1600*550*1050
WD-36GF 36 40 45 50 YC4D60-D25 40 44 1800*600*1150
WD-40GF 40 44 50 55 YCD4V33H6-75 50 55 1920*800*1100
WD-50GF 50 55 62.5 68.75 YC4D90Z-D25 60 66 1850*630*1200
WD-50GF 50 55 62.5 68.75 YC4D90-D34 60 66 2000*800*1250
WD-50GF 50 55 62.5 68.75 YC4D80-D34 50 55 1920*800*1100
WD-60GF 60 66 75 82.5 YC4A100Z-D25 70 77 1850*630*1200
WD-60GF 60 64 75 80 YC4D105-D34 70 77 2000*800*1250
WD-70GF 70 80 87.5 100 YC4D120-D31 80 88 2000*800*1250
WD-80GF 80 90 100 112.5 YC4A140L-D25 100 110 1900*650*1250
WD-80GF 80 88 100 110 YC4A140-D30 95 105 2000*850*1250
WD-80GF 80 88 100 110 YC4D140-D31 100 110 2000*800*1250
WD-90GF 90 100 112.5 125 YC4A155-D30 103 113 2000*850*1250
WD-90GF 90 100 112.5 125 YC4D155-D31 103 113 2000*850*1250
WD-100GF 100 110 125 137.5 YC6B180L-D20 120 132 2500*830*1300
WD-100GF 100 110 125 137.5 YC4A180L-D20 120 132 2100*750*1300
WD-100GF 100 110 125 137.5 YC4A165-D30 110 121 2000*850*1250
WD-110GF 110 120 137.5 150 YC4A190-D30 125 138 2000*900*1250
WD-120GF 120 132 150 165 YC6B205L-D20 138 152 2500*850*1300
WD-120GF 120 132 150 165 YCD6Q23H8-210 140 154 2500*1000*1600
WD-120GF 120 132 150 165 YC6A205-D30 138 152 2500*850*1300
WD-140GF 140 144 175 180 YC6A230-D30 155 171 2550*900*1350
WD-150GF 150 165 187.5 206.25 YC6A245L-D21 165 181 2500*970*1500
WD-150GF 150 165 187.5 206.25 YC6A245-D30 165 181 2500*1000*1500
WD-160GF 160 180 200 225 YC6A275-D30 185 203 3000*1050*1550
WD-180GF 180 200 225 250 YCD6Q33H6-260 190 209 2400*1000*1350
WD-200GF 200 220 250 275 YCA08350-D30 235 259 3100*1100*1750
WD-200GF 200 220 250 275 YC6MK350L-D20 235 258.5 3000*1100*1750
WD-200GF 200 220 250 275 YC6MK350-D30 235 259 3100*1100*1750
WD-250GF 250 275 312.5 343.75 YC6MK420L-D20 281 309 3000*1150*1750
WD-250GF 250 275 312.5 343.75 YC6MK420-D30 281 309 3100*1150*1700
WD-280GF 280 300 350 375 YC6MK450-D30 301 331 3200*1200*1750
WD-300GF 300 330 375 412.5 YC6MJ500L-D21 334 367 3150*1150*1750
WD-300GF 300 330 375 412.5 YC6K500-D30 335 370 3300*1250*1850
WD-300GF 300 330 375 412.5 YC6K500-D31 335 370 3300*1250*1850
WD-300GF 300 330 375 412.5 YC6MJ500-D30 334 367 3250*1250*1750
WD-320GF 320 350 400 437.5 YC6K520-D30 356 382 3300*1250*1850
WD-320GF 320 350 400 437.5 YC6MJ540-D30 365 402 3300*1250*1751
WD-360GF 360 400 450 500 YC6MJ600-D30 401 441 3300*1250*1800
WD-360GF 360 400 450 500 YC6T600L-D22 401 461 3350*1450*1900
WD-360GF 360 400 450 500 YC6K600-D30 401 441 3400*1150*1850
WD-360GF 360 400 450 500 YC6MJ600-D30 401 441 3300*1250*1800
WD-400GF 400 440 500 550 YC6K660-D30 441 490 3500*1500*1970
WD-400GF 400 440 500 550 YC6T660L-D20 441 485 3500*1500*1970
WD-400GF 400 440 500 550 YC6T660-D31 441 485 3500*1500*1970
WD-450GF 450 500 562.5 625 YC6TD780-D30 520 572 3580*1500*1830
WD-450GF 450 500 562.5 625 YC6TD780-D31 520 572 3580*1500*1830
WD-500GF 500 550 625 687.5 YC6TD840-D30 561 616 3650*1600*2000
WD-500GF 500 550 625 687.5 YC6TD840-D31 561 616 3650*1600*2000
WD-550GF 550 600 687.5 750 YC6TD900-D30 605 665 3750*1650*2000
WD-550GF 550 600 687.5 750 YC6TD900-D31 605 665 3750*1650*2000
WD-600GF 600 660 750 825 YC6C1020-D31 680 748 4000*1650*2100
WD-600GF 600 660 750 825 YC6TD1000-D30 668 735 3750*1650*2000
WD-650GF 650 710 800 880 YC6C1070-D31 715 787 4200*1650*2100
WD-650GF 650 710 800 880 YC6TH1070-D31 715 787 4200*1650*2100
WD-720GF 720 800 900 1000 YC6C1220-D31 815 897 4600*1800*2600
WD-730GF 730 800 900 1000 YC6TH1220-D31 815 897 4250*1700*2150
WD-800GF 800 880 1000 1100 YC12VTD1350-D30 900 990 5200*2150*2600
WD-800GF 800 900 1000 1125 YC6C1320-D31 880 968 5000*2050*2600
WD-800GF 800 880 1000 1100 YC6TH1320-D31 880 968 4650*1850*2650
WD-900GF 900 1000 1125 1250 YC12VTD1500-D30 1000 1100 5200*2150*2600
WD-900GF 900 1000 1125 1250 YC6C1520-D31 1016 1118 5000*2000*2600
WD-1000GF 1000 1100 1250 1375 YC12VTD1680-D30 1120 1230 5200*2000*2600
WD-1000GF 1000 1100 1250 1375 YC6C1660-D30 1110 1221 5100*2000*2601
WD-1000GF 1000 1100 1250 1375 YC6C1660-D31 1110 1221 5100*2000*2601
WD-1100GF 1100 1200 1375 1500 YC12VTD1830-D30 1220 1342 5400*2150*2600
WD-1200GF 1200 1320 1500 1650 YC12VC2070-D31 1380 1520 5400*2300*2600
WD-1200GF 1200 1320 1500 1650 YC12VTD2000-D30 1345 1480 5400*2150*2600
WD-1320GF 1350 1485 1687.5 1856.25 YC16VTD2270-D30 1520 1672 7350*2670*2950
WD-1320GF 1350 1485 1687.5 1856.25 YC12VC2270-D31 1520 1670 5600*2300*2600
WD-1500GF 1500 1650 1875 2062.5 YC16VTD2510-D30 1680 1850 7350*2670*2950
WD-1500GF 1500 1650 1875 2062.5 YC12VC2510-D31 1680 1850 5600*2300*2600
WD-1600GF 1600 1800 2000 2250 YC16VTD2700-D30 1805 1985 5650*2350*2600
WD-1600GF 1600 1760 2000 2200 YC12VC2700-D31 1805 1985 5650*2350*2600
WD-1700GF 1800 1980 2250 2475 YC16VC3000-D31 2005 2005/2206 7350*2670*2950
WD-1700GF 1800 1980 2250 2475 YC12VC3000-D30 2005 2206 5650*2450*2650
WD-2000GF 2000 2200 2500 2750 YC16VC3300-D31 2205 2426 7350*2670*2950
WD-2200GF 2200 2400 2750 3000 YC16VC3600-D31 2405 2646 7400*3100*3300
WD-2400GF 2400 2640 3000 3300 YC16VC4000-D31 2673 2940 7500*3200*3500

微信图片_20240427182223

60HZ

Model Power(kw) Power(kva) Engine Model Engine Power(kw) Size(mm)
Main Reserve Main Reserve Main Reserve
WD-16GF 16 17.6 20 22 YC4V35-D21 23 225 1700*700*1050
WD-24GF 24 26 30 32.5 YC4V45Z-D21 30 33 1700*700*1050
WD-30GF 30 33 37.5 41.25 YC4V55Z-D21 38 42 1700*700*1050
WD-36GF 36 40 45 50 YC4D65-D20 40 44 1800*600*1150
WD-50GF 50 55 62.5 68.75 YC4D80Z-D20 60 66 1850*630*1200
WD-60GF 60 66 75 82.5 YC4D100Z-D20 70 77 1850*630*1200
WD-80GF 80 90 100 112.5 YC4D140-D33 95 105 2000*800*1250
WD-80GF 80 88

YC6B130Z-D20 88 97 1900*650*1250
WD-90GF 90 100 112.5 125 YC4D155-D33 103 113 2000*850*1250
WD-100GF 100 110 125 137.5 YC4D180-D33 120 132 2000*850*1250
WD-100GF 100 110 125 137.5 YC6B160Z-D20 107 118 2500*830*1300
WD-120GF 120 132 150 165 YC4A205-D32 138 152 2500*1000*1600
WD-120GF 120 132 150 165 YC6B210L-D20 140 154 2500*850*1300
WD-150GF 150 160 187.5 200 YC6A245-D32 165 181 2500*1000*1500
WD-160GF 160 180 200 225 YC6A285-D32 190 209 3000*1050*1550
WD-176GF 176 190 220 237.5 YC6A305-D32 203 223 1380×800×1120
WD-200GF 200 220 250 275 YC6MK360-D30 240 264 1820×900×1370
WD-200GF 200 220 250 275 YC6MK350L-D20 240 264 3000*1100*1750
HG250GF 250 275 312.5 343.75 YC6MK420-D31 281 309 1820×900×1370
WD-250GF 250 275 312.5 343.75 YC6MK420L-D21 281 309 3000*1150*1750
WD-300GF 300 330 375 412.5 YC6MK500-D32 335 369 1820×900×1370
WD-300GF 300 330 375 412.5 YC6MJ515L-D22 346 380 3150*1150*1750
WD-400GF 400 440 500 550 YC6T660L-D21 441 485 3500*1500*1970
WD-450GF 450 500 562.5 625 YC6TD780-D32 520 572 1973×1388×1700
WD-450GF 450 500 562.5 625 YC6TD780-D32 520 572 1973×1388×1700
HG500GF 500 550 625 687.5 YC6TD840-D32 561 616 1973×1388×1700
WD-500GF 500 550 625 687.5 YC6TD840-D32 561 616 1973×1388×1700
WD-550GF 550 600 687.5 750 YC6TD940-D32 628 691 1973×1388×1700
WD-550GF 550 600 687.5 750 1973×1388×1700 628 691 1973×1388×1700
WD-600GF 600 660 750 825 YC6TD1020-D32 680 748 1941×1442×1753
WD-650GF 650 710 812.5 887.5 YC6TH1070-D33 715 787 2359×1442×1894
WD-730GF 730 800 912.5 1000 YC6TH1220-D33 815 897 2359×1442×1894
WD-800GF 800 900 1000 1125 YC12VTD1350-D32 900 990 2405×1600×1895
WD-800GF 800 9000 1000 1125 YC12VC2170-D33 900 990 2359×1442×1894
HG800GF 800 900 1000 1125 YC6TH1350-D33 900 990 2359×1442×1894
WD-900GF 900 1000 1125 1250 YC12VTD1500-D32 1000 1100 2405×1600×1895
WD-1000GF 1000 1100 1250 1375 YC12VTD1680-D32 1120 1232 2405×1600×1895
WD-1100GF 1100 1200 1375 1500 YC12VTD1860-D32 1240 1364 2405×1600×1895
WD-1200GF 1200 1300 1500 1625 YC12VTD2070-D32 1380 1520 2405×1600×1895
WD-1200GF 1200 1300 1500 1625 YC12VC2170-D33 1450 1595 3320×1644×2218
WD-1350GF 1350 1500 1687.5 1875 YC16VTD2270-D32 1520 1672 2800×1700×1950
WD-1500GF 1500 1650 1875 2062.5 YC16VTD2510-D32 1680 1850 2800×1700×1950
WD-1600GF 1600 1800 2000 2250 YC16VTD2700-D32 1805 1985 2800×1700×1950
